- Products Details
Quick Details
-
Brand Name: SINOCLIMA
Model Number: SF-550
Place of Origin: CHINA
Packaging & Delivery
- Packaging Details: Export Stanard Packing
- Delivery Detail: 7 Days
Specifications
SinoFrigo SF-550 truck refrigeration is special designed for refrigerated truck body to keep fresh,frozen and deep frozen ,powered by the engine of the vehicle, and it has great advantages in fuel saving, environmental and highly efficient.
1,SF-550 Truck Refrigeraiton Units quality you can trust on, from the world leader. Proven technology, tried and tested by previous generations of market leading direct drive units. Reliable cooling capacity and airflow, that protect cargo quality under all conditions.
2,Easy to install, all units are extra flat and lightweight. Easy to operate, in-cab command and micro-processor control, proven over many years.
3,For all ambient temperatures, with specifically designed units for high or low ambient. For all vehicles, adapts to panel van or box insulation. For chilled or frozen applications, with a choice of refrigerant.
- Ultra-Slim Evaporator with huge air volume
- In-cab Digital Controller, with e-diagnostics
- Automatic and Manual Hot Gas Defrosting
- High pressure switch&Low pressure switch
- Oil Separator
- Refrigerant Reservoir
- CPR Regulator
- Expansion Valve with MOP
Product Parameters
| Model | SF-550 | |
| Cooling Capacity | 5800W/6750Kcal/19800Btu(0℃) | |
| 3000W/3500Kcal/10000Btu(0℃) | ||
| Control Voltage | DC 12V/24V | |
| Defrosting | Hot gas defrost(Auto/Manual) | |
| Temperature Range | -25℃ ~ +30℃ | |
| Refrigerant & Volume | R404A,2.8kg±5% | |
| Airflow Volume | 2310m³/hr | |
| Compressor | Brand | QUE |
| Model | QP16 | |
| Displacement | 163cc | |
| Condenser | Type | Parallel Flow Condenser |
| Qty of Fans | 2Pcs | |
| Dimensions | 1365*420*430 mm | |
| Weight | 59Kg | |
| Evaporator | Type | Inner Grooved Copper Tube and Fin |
| Qty of Fans | 3Pcs | |
| Dimensions | 1224*508*278 mm | |
| Weight | 33Kg | |
| Recommended Box Volume | 25m³(-20℃)/35³(0℃) | |
| Optional function | Heating and Electric standby | |
